Indoor Stage Rental LED Display Viewing Angle 140°
  • Indoor Stage Rental LED Display Viewing Angle 140°
  • Indoor Stage Rental LED Display Viewing Angle 140°
  • Indoor Stage Rental LED Display Viewing Angle 140°
  • Indoor Stage Rental LED Display Viewing Angle 140°
Indoor Stage Rental LED Display Viewing Angle 140°
Indoor Stage Rental LED Display Viewing Angle 140°
Indoor Stage Rental LED Display Viewing Angle 140°
Indoor Stage Rental LED Display Viewing Angle 140°

Indoor Stage Rental LED Display Viewing Angle 140°

Payment Type:
L/C, T/T
Incoterm:
FOB, CFR, CIF, FCA, CPT
Min. Order:
1 Piece/Pieces
Min. Order:
1 Piece/Pieces
Delivery Time:
30 Days
Transportation:
Ocean, Land
Port:
Shenzhen, Guangzhou
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: China
Productivity: 6000m²/month
Supply Ability: 6000m²/month
Payment Type: L/C,T/T
Incoterm: FOB,CFR,CIF,FCA,CPT
Certificate: CCC,FCC,ETL,CE,EMC,RoHS
HS Code: 8528591090
Transportation: Ocean,Land
Port: Shenzhen,Guangzhou
Product Description
Product Description

Variety and easiness of Indoor Rental Stage LED Display:Various installation: cabinet assembly or magnetic suction installation;

Easy maintenance: optional front maintenance, back maintenance and single point maintenance according to the installation site;

High contrast mask design


Special Features:

1. High quality table lamp, the product quality is stable, reliable, and guaranteed;
2.Viewing angle of 140 degrees or more, multi direction viewing display effect is consistent;
3.Integrated blanking circuit, effectively eliminate the ghost line;
4. Multi rib structure design, to ensure that the product is not easy to tensile deformation, to ensure the integrity of the screen and the consistency of the overall.

5. Support All Media Format and Display Mode:

DVI/HDMI/3G/HD/SD/SDI display mode, applicable for TV program,VCD/DVD and live show.

Smart mode available (optional) to monitor the overall working hours and temperature of each cabinet.


Application

Advertising LED display , shopping mall LED display for logo showing ,

bank &stock exchange LED display for rates showing ,train & bus station ,

airport ,school message board, telecommunication LED Screen system for information showing and instruction , Stage performance and so on .

Stage LED Display


Specification

Model

IRA-3.9

Pixel Pitch

3.91mm

Pixel Density

65536 pixels/m2

LED Type

SMD2121

LED Configuration

1R1G1B

Cabinet Dimension

500*500mm/500*1000mm

Cabinet Resolution

128*128px/128*256px

Cabinet Weight

8kg(13kg)

Cabinet Material

die casting aluminum

Ingress Protection(front/rear)

IP40/IP21

Brightness

>1200nits

Viewing Angle(H/V)

140°/140°

Driving Method

1/16 Scan

Frame Refresh

≥ 60Hz

Data Refresh Rate

>1500Hz

Gray Scale

16bit

Power Consumption(avg.)

320w/m2

Input Voltage

AC 110/220±10%/50~60Hz

Temperature(operating/storage)

-20~50°C / -40~60°C

Humidity(operating/storage)

10%~90%RH / 10%~85%RH

MTBF

≥1000hrs

Life Span

≥50000hrs

Pixel Failure

<0.0003
