Indoor Lightweight UHD LED Display Wall Mounting Screen

Indoor Lightweight UHD LED Display Wall Mounting Screen

Get Latest Price

Payment Type:: L/C

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000m²/Month
Supply Ability:	6000m²/Month
Payment Type:	L/C
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC FCC ETL CE EMC RoHS
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

Specification

1.P1.25 indoor die casting aluminum led cabinet for fixed usage, easy and convenient to install and repairing.

2.Optional front and rear maintenance, front maintenance takes the magnet mode for easy maintenance.

3.Optional of input manually and pre-programmed (asynchronous) or displayed directly (synchronous).

4.This cabinet is not only lightweight, but also maintains a good appearance.

5.High refresh rate under lower brightness to ensure the picture line-less and stable.

6.Using high quality LED lamps, the pixel failure rate is less than 0.0003,reduce the damage of screen.

7.The whole cabinet are keeping good consistency of the whole led display,which realize seamless splicing.

8.Supports brightness adjustment and white balance custom adjustment with 256 levels.Bring perfect visual experience

9.It have a quick connect lock on the back of the cabinet. It is easy to operate.When in assembling,push the lock and then turn the revolving handle; when in dismantling: Turn the handle and pull the lock

10.Excellent heat dissipation, no noise, no fan or air conditioning.

Details

Model	IU-1.2
Pixel Pitch	1.25mm
Pixel Density	640,000px/m²
LED Type	SMD0909
LED Configuration	1R1G1B
Cabinet Dimension	400*300
Cabinet Resolution	320*240
Cabinet Weight	4.6kg/panel
Cabinet Material	die-casting
Ingress Protection(front/rear)	IP430
Brightness	>800nits
Contrast ratio	4000:1
Colours	281 trillion
Viewing Angle(H/V)	140°/140°
Driving Method	1/30 Scan
Power Consumption(avg.)	220w/m²
Power Consumption(max.)	800w/m²
Frame Refresh	≥ 60Hz
Data Refresh Rate	≥ 1500Hz
Gray Scale	16bit
Power Supply	AC 110/220±10% 50~60Hz
Temperature (operating/storage)	-20~50°C -40~60°C
Humidity(operating/storage)	10%~90%RH 10%~85%RH
MTBF	≥1000 Hours
Life Span	≥50000 Hours
Service	Front/Rear
Certification	CCC,TUV-CE,ETL

Service
1.We can offer you the best competitive price with the same even better quality.
2.We can response in time if customers have questions about the installation , usage and maintenance ect.
3.Free for the product quality problems caused by the design, manufacturing, technology installation, equipment, replacement and maintenance within two years.
4.We offer a 1-2 year warranty service according different order, and to provide free technical guidance. During the warranty period, all damaged parts could be replaced free of charge.
5.Through advanced processing technology to guarantee for high-quality and long-lifetime.
6.With production capacity of 6000 m² per month, can ensure for production cycle and delivery cycle.
