Indoor HD LED Display High Contrast LED Panel

Indoor HD LED Display High Contrast LED Panel

Get Latest Price

Payment Type:: L/C, T/T

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1 Piece/Pieces

Min. Order:: 1 Piece/Pieces

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air

Port:: Shenzhen, Guangzhou

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China
Productivity:	6000m²/Month
Supply Ability:	6000m²/Month
Payment Type:	L/C,T/T
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	CCC FCC ETL CE EMC RoHS
HS Code:	8528591090
Transportation:	Ocean,Land,Air
Port:	Shenzhen,Guangzhou

Product Description

Features
1. Ultra-Thin,Ultra light, Aluminum die casting cabinet

2.High Contrast of 4000:1,which is a very high level to ensure a vivid image of our LED screen system.

3. It is Lightweight and it owns simple structures so that it is convenient for transporting and installing.
4. Over 1500 Hz refresh rate to ensure the picture is clear and stable. Even the lower brightness but the Higher grayscale,about16 Bit,281trillion colors.
5.Long working life, up to 50,000 hours,Mean Time Between Failure is more than 1000hours,guarantee lifetime and obtain an excellent using experience.

1500 Hz Refresh Rate

Fine pitch LED Display 1.25mm/1.66mm, has Fine and rich colors and exceptional display quality
Good uniformity.Dot-to-dot correction technology provide you pure image with great gradation.

Fine pitch LED Screen

Widely applications

Long Working Life

Payment and shipment
We accept L/C, T/T and other payment methods.As for shippment,we guarantee to ship within 20-25 working days after the customer places the order, but the specific arrival time is affected by shipping and voyage.

FAQ
Q1: What's the pixel pitch for Indoor LED Display Screen ?
A1: Indoor&Outdoor Pixel Pitch0.9mm to 2.5mm

Q2: Where is it used for?
A2: It widely used for information centers, entertainment venues, conference and exhibition halls etc.

Q3: Can it play HD video?
A3: Yes, it can realize HD video function with Novastar Or Linsn controlling system.

Q4: What's the controlling system?
A4: Our standard controlling system for this model is Novastar.

Q5: How about the size of project?
A5: We can manufacture the products according to the requirements of you.So,you can offer the size with "width by height" to us. We will offer the suitable solution for your project size.

Q6:Could you please explain what is DIP and what is SMD?
A6:DIP means double in line package,we call led lamp. SMD means surface mounted device.

Parameters

Model	IU-1.2	IU-1.6
Pixel Pitch	1.25mm	1.66mm
Pixel Density	640,000px/m²	360,000px/m²
LED Type	SMD0909	SMD1010
LED Configuration	1R1G1B	1R1G1B
Cabinet Dimension	400*300	400*300
Cabinet Resolution	320*240	240*180
Cabinet Weight	4.6kg/panel	4.6kg/panel
Cabinet Material	die-casting	die-casting
Ingress Protection(front/rear)	IP30	IP30
Brightness	>800nits	>800nits
Contrast ratio	4000:01:00	4000:01:00
Colours	281 trillion	281 trillion
Viewing Angle(H/V)	140°/140°	140°/140°
Driving Method	1/30 Scan	1/32Scan
Power Consumption(avg.)	220w/m²	220w/m²
Power Consumption(max.)	800w/m²	800w/m²
Frame Refresh	≥ 60Hz	≥ 60Hz
Data Refresh Rate	≥ 1500Hz	≥ 1500Hz
Gray Scale	16bit	16bit
Power Supply	AC 110/220±10%	AC 110/220±10%
	50~60Hz	50~60Hz
Temperature	-20~50°C	-20~50°C
(operating/storage)	-40~60°C	-40~60°C
Humidity(operating/storage)	10%~90%RH	10%~90%RH
	10%~85%RH	10%~85%RH
MTBF	≥1000 Hours	≥1000 Hours
Life Span	≥50000 Hours	≥50000 Hours
Service	Front/Rear	Front/Rear
Certification	CCC,TUV-CE,ETL	CCC,TUV-CE,ETL
