Engineering Glass fiber PA6 nylon plastic sheet

Engineering Glass fiber PA6 nylon plastic sheet

Get Latest Price

Min. Order:: 100 Kilogram

Min. Order:: 100 Kilogram

Transportation:: Ocean

Port:: Shenzhen Port, Shekou Port

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen,Guangdong(Mainland)
Supply Ability:	3000 Tons/Month
Payment Type:	L/C,T/T,Western Union
Incoterm:	FOB,CFR,CIF,EXW
Certificate:	ROHS,SGS Testing Report
Transportation:	Ocean
Port:	Shenzhen Port,Shekou Port

Product Description

Introduction:

Compared with pure nylon, PA6+GF Sheet is filled with 30% glass fiber reinforced, heat resistance, strength and rigidity. It has improved creep resistance, dimensional stability, and wear resistance, and its maximum allowable temperature is high.

performance:

1.Good aging resistance.

2.good mechanical damping capacity.

3.good slidability.

4.excellent wear resistance.

5.good machinability.

6.good precision control.

7.no creep, good anti-wear performance.

8.good dimensional stability.

Application:

Widely used in chemical machinery, anti-corrosion equipment, gears and parts. Wear parts, transmission structural parts, household appliance parts, automobile manufacturing parts, screw rods to prevent mechanical parts, chemical machinery parts, chemical equipment, etc.

Details Images

Specification

Item name	Nylon GF30% Sheet
Type	extruded
Size	1000*2000mm
Thickness	10-100mm
Density	1.3g/cm3
Color	Black
Brand name	AHD
Material	PA6+GF

Physical Datasheet

Item	PA6+GF Sheet
Color	Black
Proportion	1.16g/cm³
Heat resistance (continuous)	85℃
Heat resistance (short-term)	160℃
Melting point	220℃
Linear thermal expansion coefficient (average 23~100℃)	90×10-6 m/(m.k)
Average 23--150℃	105×10-6 m/(m.k)
Flammability(UI94)	HB
Tensile modulus of elasticity	3250MPa
Dipping into water at 23℃ for 24h	86%
Dipping into water at 23℃	9%
Bending tensile stress/ Tensile stress off shock	76/- Mpa
Breaking tensile strain	>50%
Compressive stress of normal strain-1%/2%	24/46 MPa
Pendulum gap impact test	5.5 KJ/m2
Rockwell hardness	M85
Dielectric strength	25 kv/mm
Volume resistance	10 14Ω×cm
Surface resistance	10 13Ω
Relative dielectric constant-100HZ/1MHz	3.9/3.3
Critical tracking index(CTI)	600
Bonding capacity	+
Food contact	+
Acid resistance	-
Alkali resistance	+
Carbonated water resistance	+/0
Aromatic compound resistance	+/0
Katone resistance	+
