18W 24V 750mA Class 2 Led Lights Driver
- Min. Order:
- 1 Piece/Pieces
- Min. Order:
- 1 Piece/Pieces
- Transportation:
- Ocean, Air, Express, Land, Others
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 500000 |
| Supply Ability: | 500000 |
| Payment Type: | T/T,Paypal,Others |
| Incoterm: | FOB,EXW,Express Delivery,DDP,DDU |
| Certificate: | ISO9001:2015, UL, CE, FCC... |
| HS Code: | 850440 |
| Transportation: | Ocean,Air,Express,Land,Others |
| Port: | Shenzhen |
18W 24V 750mA Class 2 Led Lights Driver
The LED power driver is one 18W 24VDC 0.75Amp AC/DC single output LED lighting driver. this 24v led transformer accepts the nominal range input voltage 90~264VAC and provides four models with different output voltage, 5V, 12V, 24V, 36V, 48V respectively, that the small 18 wattage LED applications employ the most frequently. Exploiting Class II design (without FG pin) and adopting the rectangular plastic enclosure with IP20 level, led transformer is suitable for LED relatedfixture or appliance(such as LED Decorationor Advertisement devices).
Features
◆ Constant voltage design
◆ Rectangular plastic case with IP20 level
◆ Universal AC input / Full range
◆ Protections: Short circuit / Over voltage / Over current
◆ Class II power (without earth pin)
◆ Class 2 power unit
◆ Suitable for indoor LED lighting and moving sign applications
◆ 1 year warranty
Specifications
|
Color: White |
| Dimensions LxWxH (in): 3.740 x 1.732 x 0.945 |
| Dimensions LxWxH (mm): 95 x 44 x 24 |
| Input: 100-240V AC±10% 47~63Hz |
| Output type: DC and Single output |
| Working Environmen: 0℃-40℃ (0%-90%RH) |
| Storage Environment:-20℃-60%℃ (0%-90%RH) |
| Load Regulation: ±5% |
|
RoHS Compliant: Yes |
| Ripple & Noise(max): < 150mVp-p |
|
Safety Approvals: UL/cUL 8750 FCC CE ...
Mechanical Specification
|
Package
Piece/Carton(pcs)
Dimension/Carton(mm)
Dimension/White Box(mm)
Piece Weight(KG)
Gross Weight/Carton(KG)
OEM package
100
295 x 270 x 225
100 x 55 x 24
0.1
11
