100ton Screw Machine Chiller Air Cooled Water
- Payment Type:
- L/C, T/T
- Incoterm:
- FOB, CFR, CIF, EXW, FCA
- Min. Order:
- 1 Bag/Bags
- Min. Order:
- 1 Bag/Bags
- Delivery Time:
- 15 Days
- Transportation:
- Ocean, Land, Air
- Port:
- Shenzhen, Yantian, Shekou
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 300sets/Month |
| Supply Ability: | 300sets/Month |
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF,EXW,FCA |
| Certificate: | ISO9001 |
| HS Code: | 9148692090 |
| Transportation: | Ocean,Land,Air |
| Port: | Shenzhen,Yantian,Shekou |
Design features:
Well Known Brand Compressor
¨ Unit adopts Germany BITZER or Taiwan HANBELL brand semi-hermetic screw compressor. The latest 5 to 6 patented screw rotor profile with excellent efficiency.
¨ Adjustable infinite or closely stepped capacity control, features energy efficient, stable and quiet running.
¨ Most advanced patented highest precision manufacturing process.
¨ Built-in full intelligent monitoring and protection including thermal motor temperature monitoring, phase sequence monitoring, manual reset lock-out, oil temperature sensor.
¨ Wide range of refrigerant for option, including R134a, R407c and R22(R404a, R507c upon request).
Microprogramming Control System
¨ Industrial PLC centralized control combined with compressor capacity control system, precisely monitor.
¨ Integrated protection for low temperature, high/low pressure, anti-freezing, phase missing, anti-phase, overload, motor over temperature, oil differential, flow switch, start up latency.
¨ Optional operation language, menu leading, unit running state easy to adjust.
Easy Installation, Reliable Running
¨ Closely stepped start-up, minimize impact to electricity.
¨ Steady and safe running, low vibration, easy for installation.
¨ Compact structure, less space demand and light in weight, easy for transport and installation.
¨ Completely wired, inspected and tested pre-delivery, saving installation time and cost.
FAQ:
A: Low MOQ, 1pc for sample checking is available.
Q2. How do you ship the goods and how long does it take to arrive?
A: We usually ship bu DHL, UPS, Fedex or TNT. It usually takes 10 days to arrive. Airline and sea shipping are also available.
Q3. Do you offer guarantee for the products?
A: Yeas, we offer 12 months warranty to our products.
Q4: Where the application?
A: Our products have been widely used in many industries, like machine tool, data processing, telecommunications, financial, metallurgy, medical, building material, cars and war industry and etc.
Q5: Are your products can be customized?
A: Yes. Also welcomed to customized non-standard products, can achieve to -180 degree Celsius.
Q6: Whats your payment term?
A: International term-30% deposit for production, 70% balance before shipment.
| Model | KDS-100SLA | ||
| Cooling capacity | KW | 335.0 | |
| kcal/h | 288,100 | ||
| Input power | kW | 64.8 | |
| Frozen fluid flow | m3/h | 54.0 | |
| Cooled water flow | m3/h | 68 | |
| Power supply | 3PH-380V-50HZ（200V/220V/415V 50HZ/60HZ） | ||
| Compressor | Type | Semi-Hermetic screw type | |
| Number | Set | 1 | |
| Start-up mode | Y - △ | ||
| Capacity control type(%) | 0~100(4 segments of tolerance:0, 33, 66, 100) | ||
| Power(kW) | 70.0 | ||
| Refrigeration oil | Type | SUNISO 4GS | |
| Charge | L | 16.0 | |
| Refrigerant | Type | R-22(R407c/R134a) | |
| Control mode | Thermostatic expansion valve | ||
| Filling amount(kg) | 54.0 | ||
| Evaporator | Type | Shell and Tube | |
| Pipe | B | PT 4" | |
| Condenser | Type | Shell and Tube | |
| Protective device | Compressor overheating,over current,high and low pressure,over temperature,flow switch,phase sequence,phase-missing,exhaust overheating,anti-freezing. | ||
| Dimension | L | mm | 2800 |
| W | mm | 850 | |
| H | mm | 1800 | |
| Weight | kg | 1930 | |
