G215HCJ-L01 21.5 inch Innolux TFT-LCD

This Innolux TFT-LCD is a 21.5 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. G215HCJ-L01 supports display 1920(RGB)×1080 (FHD) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 476.064(W)×267.786(H) mm, outline size of 497.6(W)×287(H)×14(D) mm, viewing area size of 479.3(W)×270.9(H) mm, with surface treament of Antiglare (Haze 25%), Hard coating (3H), net weight of 1.94±0.08Kgs. As a AAS, Normally Black, Transmissive LCM product, G215HCJ-L01 can provides 400 cd/m² display brightness 1000:1 transimissive contrast ratio, 89/89/89/89 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 8/7 (Typ.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 47% (NTSC). This product adopted WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, With LED Driver. G215HCJ-L01 utilizes LVDS (2 ch, 8-bit) as it's signal inputting systerm, which connected by 30 pins Connector with power supply voltage of 5.0V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.

We are able to offer AD board for this display to support VGA video input.

Product Picture:
