TM035KDH18 3.5 inch Tianma TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 10000 pcs |
| Supply Ability: | 10000 pcs |
| Payment Type: | T/T,Paypal |
| Incoterm: | EXW,FOB |
| Certificate: | CE, ROHS |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shenzhen |
TM035KDH18 is a 3.5 inch diagonal a-Si TFT-LCD display screen product from TIANMA, with a built-in WLED backlight, without backlight driver, without touch screen. This Tianma TFT-LCD is a 3.5 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. TM035KDH18 supports display 320(RGB)×240 (QVGA) with aspect ratio of 4:3 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 70.08(W)×52.56(H) mm, outline size of 76.9(W)×63.9(H)×3.35(D) mm, viewing area size of 72.88(W)×55.36(H) mm, net weight of TBD. As a TN, Normally White, Transmissive LCM product, TM035KDH18 can provides 480 cd/m² display brightness 300:1 transimissive contrast ratio, 45/45/30/60 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on 12 o'clock , and response time of 25 (Typ.)(Tr+Td) ms., thus presenting a palette of 65K/262K colors, also with performance of color gamut 50% (NTSC). This product adopted 6S1P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, external backlight driver is additionally needed. TM035KDH18 utilizes Parallel RGB (1 ch, 8-bit) + SPI as it's signal inputting systerm, which connected by 54 pins FPC with power supply voltage of 2.8V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model P/N |
TM035KDH18 |
|
Brand |
TIANMA |
|
Diagonal Size |
3.5" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
320(RGB)×240, QVGA 115PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
70.08(W)×52.56(H) mm |
|
Bezel Opening |
72.88(W)×55.36(H) mm |
|
Outline Size |
76.9(W)×63.9(H) ×3.35(D) mm |
|
Brightness |
480 cd/m² (Typ.) |
|
Contrast Ratio |
300:1 (Typ.) (TM) |
|
Viewing Angle |
45/45/30/60 (Typ.)(CR≥10) |
|
Display Mode |
TN, Normally White, Transmissive |
|
Best View on |
12 o'clock |
|
Response Time |
25 (Typ.)(Tr+Td) |
|
Display Colors |
65K/262K 50% NTSC |
|
Lamp Type |
6S1P WLED , 50K hours , Without Driver |
|
Frequency |
60Hz |
|
Touch Screen |
Without |
|
Panel Weight |
TBD |
|
Signal Interface |
Parallel RGB (1 ch, 8-bit) + SPI , 54 pins FPC |
|
Input Voltage |
2.8V (Typ.) |
|
Environment |
Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
Product Picture:
