TM042NDZP90-00 4.2 Inch Tianma TFT-LCD
-
$25.001-99 Piece/Pieces
-
$20.00≥100 Piece/Pieces
- Transportation:
- Ocean, Land, Air, Express
- Port:
- Shenzhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Productivity: | 10000 pcs |
| Supply Ability: | 10000 pcs |
| Payment Type: | Paypal,T/T |
| Incoterm: | FOB,EXW |
| Certificate: | CE,ROHS |
| Transportation: | Ocean,Land,Air,Express |
| Port: | Shenzhen |
TM042NDZP90-00 is a 4.2 inch diagonal a-Si TFT-LCD display screen product from TIANMA, with a built-in WLED backlight, without backlight driver, without touch screen. This Tianma TFT-LCD is a 4.2 inch with Consumer Lcd Display, it have LCD Controller, Backlight Cable and Tft Color Screen. TM042NDZP90-00 supports display 480(RGB)×272 (WQVGA) with aspect ratio of 16:9 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 92.88(W)×52.632(H) mm, outline size of 102.5(W)×67(H)×27.1(D) mm, with surface treament of Without Polarizer, net weight of 78.0g (Typ.). As a SFT, Normally Black, Transmissive LCM product, TM042NDZP90-00 can provides 750 cd/m² display brightness 900:1 transimissive contrast ratio, 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 25 (Typ.)(Tr+Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 8-bit gray scale signal for each dot, thus presenting a palette of 16.7M colors, also with performance of color gamut 55% (NTSC). This product adopted 3 strings WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 10K hours, external backlight driver is additionally needed. TM042NDZP90-00 utilizes Parallel RGB (1 ch, 8-bit) + SPI as it's signal inputting systerm, which connected by 50 pins FPC with power supply voltage of 3.3V (Typ.). It's typical vertical frame rate (Fv) is 60Hz.
We are able to offer AD board for this display to support VGA video input.
|
Model P/N |
TM042NDZP90-00 |
|
Brand |
TIANMA |
|
Diagonal Size |
4.2" |
|
Panel Type |
a-Si TFT-LCD, LCM |
|
Resolution |
480(RGB)×272, WQVGA 131PPI |
|
Pixel Format |
RGB Vertical Stripe |
|
Active Area |
92.88(W)×52.632(H) mm |
|
Outline(mm) |
102.5 × 67 × 27.1 (H×V×D) |
|
Treatment |
Without Polarizer |
|
Luminance |
750 cd/m² (Typ.) |
|
Contrast Ratio |
900 : 1 (Typ.) (TM) |
|
Viewing Angle |
88/88/88/88 (Typ.)(CR≥10) |
|
Response |
25 (Typ.)(Tr+Td) ms |
|
Good View at |
Symmetry |
|
Work Mode |
SFT, Normally Black, Transmissive |
|
Color Depth |
16.7M 55% NTSC |
|
Backlight |
3 strings WLED , 10K hours , No Driver |
|
Mass |
78.0g (Typ.) |
|
Refresh Rate |
60Hz |
|
Touchscreen |
Without |
|
Signal Type |
Parallel RGB (1 ch, 8-bit) + SPI , 50 pins FPC |
|
Voltage Supply |
3.3V (Typ.) |
|
Max. Ratings |
Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 3.0G (29.4 m/s²) |
Product Picture:
