Contact NowDR25 Mechanical Protect Heat Shrink Tubing For Sensitive components
Description
SINOFUJI Mechanical Protect Heat Shrink Tubing is highly abrasion and cut-through resistant and can withstand a wide variety of fuels, lubricants, acids and highly corrosive fluids at temperatures up to 200°C. In addition to its high continuous operating temperature and chemical-resistance properties, Mechanical Protect Heat Shrink Tubing is very flexible and is easily marked by hot-stamp or print wheel methods. When heated in excess of 175°C (347°F), SINOFUJI Mechanical Protect Heat Shrink Tubing rapidly shrinks to a skintight fit. SINOFUJI tubing is rated for continuous operation from –55°C (–67°F) to 200°C (392°F).135°C/275°F
Cross-linked fluoroelastomer
Superior abrasion resistance
High temperature resistance
Excellent resistance to aggressive chemicals and slovents
Available with various wall thickness
Continuous operating temperature:-55℃~200℃
Min. Full recovery temp.: 175 ℃
RoHS compliant
Flammability:UL 224 VW-1
Meets: SAE-AMS-DTL-23053/13
Shrink ratio
Modified fluoroelastomer heat shrink tubing has a 2:1 shrink ratio. When freely recovered, the tubing will
shrink to 50% of its as-supplied internal diameter. The recovered wall thickness is proportional to the degree of recovery.
Typical Applications
Because of its outstanding high temperature fluid performance,modified fluoroelastomer heat shrink tubing is often used to protect wiring and component covers in aircraft/aerospace applications including
electronic control systems and hydraulic fluid transport mechanisms and in chemical plants.
Technical Data
|
Property |
Test Method |
Typical Data |
|
|
Property of jacket |
|||
|
Tensile strength |
ASTM D 2671 |
≥8.5 MPa |
|
|
Ultimate elongation |
ASTM D 2671 |
≥250% |
|
|
Heat aging |
250℃, 168 hrs. |
≥8 MPa |
|
|
Tensile strength |
≥200% |
|
|
|
Ultimate elongation |
|
||
|
Heat shock |
300℃,4 hrs. |
No cracking |
|
|
Flammability |
VW-1 |
Pass |
|
|
Volume resistance |
IEC 93 |
≥1014Ω .cm |
|
|
Dielectric strength |
ASTM D 2671 |
≥7.9kV/mm |
|
|
Copper stability |
UL 224 |
Pass |
|
|
Copper corrosion |
UL 224 |
No corrosion |
|
Structure
Dimension
|
Size (inch) |
Size (mm) |
As Supplied (mm) |
After Recovery (mm) |
Standard Length (m/spool) |
|
|
D* (Min.) |
d*(Max.) |
w*(Min.) |
|||
|
TZRS-VT200(2X) Fluoroelastomer tubing |
|||||
|
1/8 |
3.2 |
3.2 |
1.6 |
0.80 |
100 |
|
3/16 |
4.8 |
4.8 |
2.4 |
0.95 |
100 |
|
1/4 |
6.4 |
6.4 |
3.2 |
0.98 |
50 |
|
3/8 |
9.5 |
9.5 |
4.8 |
1.00 |
50 |
|
1/2 |
12.7 |
12.7 |
6.4 |
1.16 |
30 |
|
3/4 |
19.1 |
19.1 |
9.5 |
1.49 |
30 |
|
1 |
25.4 |
25.4 |
12.7 |
1.85 |
30 |
|
1 1/2 |
38.1 |
38.1 |
19.1 |
2.10 |
15 |
|
2 |
50.8 |
50.8 |
25.4 |
2.10 |
15 |
|
TZRS-VT200(2X) Thin wall fluoroelastomer tubing |
|||||
|
3/8 |
9.5 |
9.5 |
4.8 |
1.00 |
50 |
|
1/2 |
12.7 |
12.7 |
6.4 |
1.00 |
30 |
|
5/8 |
15.9 |
15.9 |
7.9 |
1.20 |
30 |
|
3/4 |
19.1 |
19.1 |
9.5 |
1.25 |
30 |
|
7/8 |
22.0 |
22.0 |
11.0 |
1.37 |
30 |
|
1 |
25.4 |
25.4 |
12.7 |
1.37 |
30 |
|
1 1/4 |
31.8 |
31.8 |
15.7 |
1.54 |
30 |
|
1 1/2 |
38.1 |
38.1 |
19.0 |
1.54 |
15 |
|
2 |
50.8 |
50.8 |
25.4 |
1.82 |
15 |
Note:
D* = Inner diameter as supplied
d* = Inner diameter after fully recovered
w*= Wall thickness after fully recovered
