2.8 inch TFT LCD Display Module Screen

Get Latest Price

Payment Type:: T/T

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T

Product Description

A thin-film transistor LCD is a type of LCD display that’s characterized by the use of thin-film transistor technology. Basically, it’s an active-matrix LCD in which each pixel is given its own dedicated transistor. Passive-matrix LCDs, on the other hand, have fewer transistors. Thin-film transistor LCDs are often preferred over other types of LCDs for several reasons. First, they are typically brighter than their counterparts.Furthermore, thin-film transistor LCDs are highly efficient, meaning they don’t consume a lot of energy.

ITEM	Sandard value	Unit
LCD Type	Normally Black	--
Drive element	TFT active matrix	--
Number of pixels	240*3RGB(H)X320(V)	Dots
Pixel arrangement	RGB stripe	--
Pixel Pitch (H*V)	0.180(H)x 0.180(V)	mm
Active area	43.20(H) × 57.60(V)	mm
Viewing direction	ALL O’CLOCK
TFT Driver IC	ST7789V	-
TFT interface	16bit MCU interface	-
Approx. Weight	TBD	g
LCM Size(WHT)	50.00(W) x69.20(H) x2.11(T)	mm
LCM+CTP Size(WHT)	52.90(W) x79.30(H) x3.71(T)	mm
Touch structure	G+G
Touch Driver IC	GT911	-
Touch Interface	I2C
