5 Axis Cnc Machining prototype

Five-axis CNC machining center is more and more widely used in various fields. In practical application, when people encounter the high efficiency and high-quality machining problem of irregular complex parts, five-axis linkage technology is undoubtedly an important means to solve such problems. More and more manufacturers tend to look for five-axis equipment to meet the high efficiency and high-quality machining.

Five-axis machining center is a kind of advanced cutting method using the spindle rotation to complete the cutting, so that the workpiece in the shape accuracy, position accuracy and complete the workpiece surface production processing and other aspects can meet the application requirements, the equipment is not simply turn-milling machine. But the use of five-axis machining center spindle movement to achieve a variety of mold, plate, furniture production, and processing, this is in the current numerical control technology to get a great development of the situation, a new cutting practice and cutting skills.

Five-axis machining center machining technology refers to the machining technology in that a complex surface needs five independent axes to carry out numerical control interpolation motion together to obtain a smooth and flat surface. In theory, any complex surface can be represented in terms of X, Y, and Z coordinates, but the actual tool for machining is not a point, but a solid object of a certain size. In order to avoid interference between the cutter and the machined surface and ensure the consistency of the cutting conditions at each point of the surface, it is necessary to adjust the included Angle between the cutter axis and the normal vector of the surface in the two-dimensional direction.


The number of axes in a five-axis machining center refers to the number of axes that need to move independently when machining the same surface, rather than the number of controllable axes owned by a CNC system.
