Standard UV laser marking machine

Features:
UV marking machine series products are integrated into international advanced technology. High energy UV photons directly destroy the molecular bonds on the surface of many non-metallic materials, and make molecules separate from objects. This method will not generate high heat. UV laser gathers light spot very little and processing almost has no thermal impact. Therefore, it is called cold processing, so it is suitable for super fine marking and carving of special materials.
Application fields:
UV laser has small spot and has little heat effect, so it is called cold processing, so it is suitable for super fine marking and carving of special materials. Mainly used in the high-end market of ultra-fine processing, marking the surface of packaging bottles of cosmetics, drugs, food and other polymer materials; Marking and scribing of flexible PCB board; Silicon wafer micro hole, blind hole processing; LCD LCD glass two-dimensional code marking, glassware marking, metal surface coating removal, plastic keys, electronic components, communication equipment, etc.
Product advantages:
The UV laser wave length and focus spot are smaller, which can achieve super fine marking; It belongs to cold working, with small heat affected zone, avoiding damage to processed materials and high yield; It is widely used in the field of materials, which makes up for the shortage of infrared laser processing ability; The high speed digital vibration mirror is used, which has the advantages of fast marking speed, high efficiency and high precision; No need of consumables, low cost of use and maintenance; The performance of the whole machine is stable and can be operated for a long time.
Technical parameters:
model; UV-3DL、UV-5DL、UV-7DL、UV-10DL、UV-5LZ、UV-3YNUV-5YN、UV-7YN、UV-10YN、UV-3YG、UV-5YG、UV-7YG、UV-10YG、UV-15YG、UV-3DS
Laser wavelength: 355nm
Laser power: 3W, 5W, 7W, 10W
Laser lifetime: ≤ 80000 hours
Beam quality: M2 < 1.1mm
Marking speed: 600-1000 characters / S
Marking line width: ≤ 0.01mm
Mark line speed: ≤ 0.01mm
The best operating environment temperature: 18 ℃ -26 ℃, humidity: 10% - 80%
Power demand: 220 V / 50 Hz / 60 Hz / 16 A
Cooling mode: water cooling (air cooling optional)
Weight: about 140kg
Overall dimension: 102CM * 76cm * 148cm (L * w * h)
Repeatability: ± 0.001mm
Engraving range: 70mm * 70mm (other ranges can be selected)
Continuous operation time: 24 hours
