Three axis welding table

Two axis welding table zlpc201
Industrial PC control, dimension: (L * w * h): 1050 * 600 * 1200 (mm);
The workpiece to be welded moves in two dimensions, in which the X and Y axes are driven by step, the stroke is 200 mm * 150 mm, and the positioning repetition accuracy is up to 100% ± 03mm, which can be used for welding point, straight line, circle, ellipse and square plane arbitrary trajectory;
The laser head is 300 mm, with manual lifting and focusing, left and right 45 °， Looking down 30 ° The tilt posture can be adjusted manually;
This worktable is widely used in plane track welding of general components

Three axis welding worktable zlpc301
Industrial PC control, dimension: (L * w * h): 850 * 1100 * 1450 (mm);
The whole system adopts three-axis design (can be designed as two axis or four axis), the laser exit head moves, in which the X and Y axes are servo driven, the stroke is 300 mm * 200 mm * 100 mm, and the positioning repetition accuracy is up to 100 mm ± 03mm, laser head 45 ° It can be adjusted manually;
The laser head can move in the space track, and can weld any plane track such as point, line, circle, ellipse and square, as well as simple space geometric track;
This worktable is widely used in the plane track welding of general components, especially for the welding of electronic components, fan blades, it digital shell and other hardware.
