moldmaking rubber
- Payment Type:
- T/T, L/C, Western Union
- Incoterm:
- EXW
- Min. Order:
- 200 Kilogram
- Min. Order:
- 200 Kilogram
- Delivery Time:
- 3 Days
- Transportation:
- Ocean, Land, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Shenzhen |
|---|---|
| Productivity: | 8 tons/day |
| Payment Type: | T/T,L/C,Western Union |
| Incoterm: | EXW |
| Transportation: | Ocean,Land,Air |
1. Mouldmaking rubber Description:
Mouldmaking rubber is two-component material consiting of part A silicone rubber, part B catalyst. It cures at room temperature by condensation raction.
A range of materials can be cast into a cured silicone molds, like plaster, gypsum, polyurethane, polyester, resin, cement, wax and so on are usually used.
2. Moldmaking silicone FEATURES:
1). Two-part silicon rubber:flowable liquid silicon and curing agent.
2). Cures at room temperature within 3-5 hours.
3). An exceptional fluidity and good operability, easy to demold.
4). Good tensile and tear strength, low shrinkage.
5). High duplication times.
3. HY6 series datasheet
|
Model |
620 |
625 |
630 |
640 |
|
Mixing proportion of catalyst (%) |
5% |
5% |
5% |
5% |
|
Density (23 °C) |
1.10 |
1.11 |
1.12 |
1.11 |
|
Hardness (A°) |
18~22 |
23~25 |
28~32 |
40 |
|
Viscosity (23 °C, mpa.s) |
10000~13000 |
17000~19000 |
24 000~29000 |
8000~10000 |
|
Pot life (mins) |
30~40 |
30~40 |
30~40 |
40~50 |
|
Cure time (23 °C) |
4~6 hrs |
4~6 hrs |
4~6 hrs |
6~8 hrs |
|
Tensile-strength (mpa ) |
≥ 2.8 |
≥3.0 |
≥3.6 |
≥2.8 |
|
Tear-strength (kN/m) |
≥ 2.0 |
≥2.5 |
≥2.7 |
≥1.6 |
|
Elongation-break(%) |
≥ 400 |
≥400 |
≥ 420 |
≥260 |
|
Shrink Factor (%) |
≤ 0.3 |
≤0.3 |
≤0.3 |
≤0.3 |
