4.3 inch 800x480 TFT display LCD screen IPS-type
- Min. Order:
- 3000 Piece/Pieces
- Min. Order:
- 3000 Piece/Pieces
- Transportation:
- Ocean, Land, Air
- Port:
- ShenZhen
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | china |
|---|---|
| Productivity: | more |
| Supply Ability: | strong |
| Payment Type: | T/T |
| Incoterm: | FOB |
| Transportation: | Ocean,Land,Air |
| Port: | ShenZhen |
Model Number: K430H40110
Brand Name: Newvison
Origin: China (mainland)
Key Specifications/Special Features:
LCD size: 4.3 inch (Diagonal)
Number of pixels: 800(H) RGB x 480(V)
Module size: 105.50(W)x 67.20(H)x 2.9(T) mm
Active area: 95.04x 53.86 mm
Interface: RGB
Luminance (cd/m2): 450 (TYP)
Viewing direction: Full
Shipping Information:
- FOB Port: Shenzhen
- Lead Time: 20 - 25 days
- HTS Code: 9013.80.90 00
- Dimensions per Unit: 10.55 × 6.72 × 0.29 Centimeters
- Weight per Unit: 10.4 Kilograms
- Units per Export Carton: 200
- Export Carton Dimensions L/W/H: 38.5 × 31.5 × 22.7 Centimeters
- Export Carton Weight: 1.86 Kilograms
Main Export Markets:
- Asia
- Australasia
- Central/South America
- Eastern Europe
- Mid East/Africa
- North America
- Western Europe
Any third-party trademarks or images shown here are for reference purposes only Liquid Crystal Display. We are not authorized to sell any items bearing such trademarks.
2 Change the requirements of the inverter TFT LCD Display
In an 18-inch standard flat panel display (FPD) using CCFL backlit surface lighting, the display logic circuit and DC/AC inverter may require 10W and 55W of power, respectively. Of the total power of 65W, only a very small part is converted into light, and most of it is converted into heat LCD Module.
The back light source of multiple lamps also has serious heat scattering, which makes its optical efficiency very low LCD Display Module. Due to the thinness of the manufactured FPD components, the heat exceeding 50W has to be dissipated in a relatively small space LCD TFT.
In order to achieve the best heat management, proper ventilation measures must be adopted for the display enclosure. Moreover, all components including: housing, CCFL, display and inverter, must be designed and specified for the actual operating temperature (up to 150°F) in the display housing. Today's ideal inverter for multi-lamp FPD can provide about 90% efficiency and direct connection to the display, low power consumption, flicker-free 0-100% brightness control, up to 60W output power, and integrated input and output connectors Active Matrix LCD.
