Glass Advertising Video Wall P10 Led Transparent Display
-
$2450.001-49 Square Meter
-
$2280.0050-99 Square Meter
-
$2020.00≥100 Square Meter
- Transportation:
- Ocean, Land, Air, Express
- Port:
- GuangZhou, ShenZhen, ShangHai
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | ShenZhen,China |
|---|---|
| Productivity: | 99999 square meters per month |
| Supply Ability: | 100000 square meters per month |
| Payment Type: | Western Union,Money Gram,Paypal,T/T,L/C,Bank account |
| Incoterm: | FOB,CIF,EXW,DDP,DDU,Express Delivery |
| Certificate: | CE,RoHs,IOS9001 |
| HS Code: | 7020001100 |
| Transportation: | Ocean,Land,Air,Express |
| Port: | GuangZhou,ShenZhen,ShangHai |
Product Description
Yuguang's photoelectric glass is an independent research and development process，not belong to ITO，also not belong to glass line，P20 Transparent Led Screen
we use FPC flexible circuit board，hollow out at least 80% of the area，reserve 20% of the area to install LED Handle Display Glass，then splice the flexible
circuit board to achieve a large area of the lamp board size，P10 Outdoor Led Display Module using large-area glass to sandwich the light board，has module
standardization，have unity，P10 Outdoor Led Display Panel Module convenient production，inventory can be prepared，Transparent Led Glass Display therefore,
for large-format glass，Transparent Led Screen the size of the glass itself has little to do with the production of the circuit，the size of the glass can be arbitrarily
defined according to the construction environment,LED Transparent Screen just arrange the light board modules to the corresponding size for clamping. Similar
to our company's other product smart film, the smart film is cut from a large size to a small size to match the glass to make smart glass, P5*P10 Transparent LED Screen
photoelectric glass is made by splicing small-sized lamp panels to a size suitable for glass.
P10*p10 Transparent Led Screen
Product Specification
|
Specification |
P5*10 |
P10 |
P10*20 |
P20 |
|
Gray level |
256 Level |
256 Level |
256 Level |
256 Level |
|
Drive mode |
High-speed sweep 1 |
High-speed sweep 1 |
High-speed sweep 1 |
High-speed sweep 1 |
|
Vertrefresh |
≥1920 |
≥1920 |
≥1920 |
≥1920 |
|
Visual angle |
≥160 |
≥160 |
≥160 |
≥160 |
|
Optimum viewing distance |
≥7.5 m |
≥15 m |
≥23 m |
≥30 m |
|
Intensity control |
256 Level |
256 Level |
256 Level |
256 Level |
|
Control system |
Send card/playbox |
Send card/playbox |
Send card/playbox |
Send card/playbox |
|
Specification |
P5*10 |
P10 |
P10*20 |
P20 |
|
VPSS |
Multimedia |
Multimedia |
Multimedia |
Multimedia |
|
Voltage |
+5VDC |
+5VDC |
+5VDC |
+5VDC |
|
Mean square power |
400W |
250W |
150W |
80W |
|
Maximum square power |
800W |
500W |
300W |
150W |
|
The screen body material |
Tempered glass |
Tempered glass |
Tempered glass |
Tempered glass |
|
Working Temperature |
-20~55℃ |
-20~55℃ |
-20~55℃ |
-20~55℃ |
|
Storage temperature |
-40~80℃ |
-40~80℃ |
-40~80℃ |
-40~80℃ |
|
Specification |
P5*10 |
P10 |
P10*20 |
P20 |
|
Operating humidity |
10-90% |
10-90% |
10-90% |
10-90% |
|
Storage humidity |
5-95% |
5-95% |
5-95% |
5-95% |
|
Image clarity |
80% |
80% |
90% |
90% |
Unique Perspective experience Does not affect lignting Window into advertising space
Glass Advertising Video Wall P10 Led Transparent Display
Building Glass Led Display
Factory
After sales & clients comments
P10 Outdoor Led Display Screen Module
