Detailed description of P20 led display
Ph20mm indoor 2rgb full color LED display details
These series products are durable IP65 rated, available:PH10mm, PH12mm, PH14mm,PH16mm, PH18mm, PH20mm, PH22mm, PH25mm, PH30mm, and PH31.25mm total 10 formats, and deliver high-resolution, full color images with unequalled brightness and contrast levels.
It's purpose built for life on the road, and our indoor H series LED modules form part of a total rental solution that includes hanging rental structures, sturdy flight cases as well as powerful, user-friendly control software, which allows you to have your display installed and calibrated in no time.
The brightness of SBC's indoor LED display mainly at 6500cd/m2,and in some solution with especial design it can be more than 10000cd/m2 durable. Delivers superb contrast levels even in the brightest of sunlight ,our indoor LED display also make a good behavior.
As of above, This product lines are typical applications include billboard, indoor media, indoor advertising, mobile displays and sport events.
Parameter Description
|
Type |
indoor Led Display |
|
Best Viewing Distance(m) |
69 |
|
Pixel Pitch(mm) |
20 |
|
Pixel Density(Dots/sqm) |
2500 |
|
Configuration |
1R1G1B |
|
Module Size(mm) |
320*160 |
|
Unit Box Pixel(Dots) |
64*48 |
|
Cabinet Size(W*H*T) |
1280* 960*120 |
|
Cabinet Weight(Kg) |
60 |
|
Brightness(cd/sqm) |
8000 |
|
Refresh Frame Frequency( Hz) |
1000 |
|
MTBF(H) |
10000 |
|
Maximum Power Consumption(W/sqm) |
550 |
|
Average Power Consumption(W/sqm) |
300 |
|
Left/right Viewing Angle(Degree) |
140 |
|
Grey Scale |
12bit |
|
Display Color |
16777216colors |
|
IP Standard |
IP65 |
|
Display Module Brightness Uniformity |
5% |
|
Pixels Out Of Control Rate(Dots) |
1/100000 |
|
Life Span(H) |
100000 |
|
System Working Environment Temperature |
-20°C~+60°C |
|
System Working Environment Humidity |
10%RH~90%RH |
