FTP cat5e network cable Tri-shield cable
Your message must be between 20 to 2000 characters
Contact NowFTP cat5e network cable Tri-shield cable
Brand:Brothers-Y
Shenzhen Brother Young Development Co., ltd was established in 2002 and is a professional designer and manufacturer of copper cable, coaxial cable and fiber cable. Our products include full sets of network accessories and all kinds of cables & network layout projects.
- Fast and reliable connection
- Twisted pairs with bright color easy recognition
- tipvord and footmark for convenient use
- smooth jacket for easy pulling in tight space
- colors:light gray ,blue ,white or as per customer’s requirement
specifications:
- inner material: Bare copper/CCA/AL/CCA+CCS twisted pairs
- diameter of conductor: 24/23AWG
- Insulation: PE
- Jacket: PVC, ROHS, LSZ
- Transmission speed: 350M
- PVC color : optional
- Certificate: CE,ROHS,ISO,SGS,FLUKE,UL
|
Electrical performance: |
||||||||||
|
Frequency(MHz) |
1 |
2 |
10 |
16 |
20 |
31.2 |
62.5 |
100 |
155 |
250 |
|
Attenuation(dB/100m) |
1.8 |
3.6 |
5.6 |
7.1 |
8.0 |
9.9 |
14.2 |
18.1 |
23.3 |
29.1 |
|
NEXT(dB) |
80 |
73 |
67 |
64 |
61 |
57 |
53 |
48 |
46 |
42 |
|
PSNEXT(dB) |
78 |
71 |
65 |
62 |
59 |
55 |
51 |
46 |
44 |
40 |
|
ACR(dB) |
78 |
67 |
61 |
57 |
53 |
47 |
39 |
30 |
23 |
13 |
|
PSACR(dB) |
76 |
67 |
59 |
55 |
51 |
45 |
37 |
28 |
21 |
11 |
|
ELFEXT(dB) |
86 |
78 |
67 |
60 |
56 |
53 |
46 |
40 |
36 |
32 |
|
PSELFEXT(dB) |
84 |
76 |
65 |
58 |
54 |
51 |
44 |
38 |
34 |
30 |
|
Return Loss(dB) |
27 |
32 |
32 |
32 |
32 |
32 |
30 |
30 |
28 |
25 |
Electrical Characteristic:
-
Impedance (ohms): 100 ohm+/- 15 ohm
-
DC Rersistance: <=6.58Ω/100M
-
Resistance imbalance: <=2.5%
-
Insulation resistance: 5000MΩ.KM
Certificates:
-
RoHS compliant.
-
Fluke Testing.
-
UL certificate.
-
CE certificates.
Flame resistance level:
-
CMX. CM, MP, CMG, MPG, CMR, MPR
PACKAGE & DELIVERY:
-
20 feet container: 1050 boxes
-
40 feet container: 2100 boxes
-
40 hq container : 2500 boxes
Packing detail:
-
inner box:305M/1000ft cable-size: 34.5*34.5*19.5 CM ;carton: 61.5*35.8*36.5(3 boxes in a carton)
-
wooden drum can be supplied.
-
Delivery Detail: after checking the box and printing detail, 7-15 days for delivery
