10.4 Inch Open Frame Touch Lcd Monitor

Get Latest Price

Min. Order:: 1

Min. Order:: 1

Delivery Time:: 20 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Certificate:	EMI/EMC CE FCC Rohs

Product Description

=Product features=
  10.4 Inch Open Frame Touch Lcd Monitor
  640x480/ 800x600 Resolution(Optional)
  230 / 400 cd/m2(Optional)
  VGA Signal Input
  12V 4A DC Input
  Touch (Optional)
  Meet FCC, CE, CCC, RoHS Certification
  Operating Temp:-20~70

Product Specifications

LCD
Panel Type	AUO LCD Panel (Optional)
Resolution	800*600
Display Area(mm)	211.2(H)*158.4(V)
Brightness	230nits
Contrast Ratio	500:1
Colors	16.2M/262k colors
View Angle	70/70/55/65
Backlight Lifetime	30000
ODS Control	Auto Menu Select(+,-)Exit On/Off

Touch Screen
Type	No(Optional)
Resolution(pixel)	No
Touch Transmittance	No

Interface
Signal Input	VGA+DVI(15 Pin D-sub/DVI-D Connector) AV Input/Video Input/Video Input/Audio Input(Optional)
Touch Connectors	USB / RS232(Optional)

Power
Power Input	DC12V/4A (50~61HZ)-DC Jack (2.0mm)
Power Consumption	is less than or equal to 36W

Mechanical
Material	Steel chassis
Mounting	Support VESA Wall Mount and Embedded Mount
Dimensions	219.8(H)180.0(V)33.5(D)

Environment
Operating Temp	-20~70
Storage Temp	-30~80
Relative Humidity	10~90% @40C^o Non-condensing without touch screen
Vibration	1G peak,5~500Hz(Random)
Shock	15G peak acceleration (11msec.duration)
Rating	Meet EMI/EMC CE FCC Rohs

Ordering Information
GHK-10OP-NA	10.4 Inch Open Frame Lcd Monitor
GHK-10OP-TA	10.4 Inch Open Frame Touch Monitor
