12.1 Inch Open Frame Touch Lcd Monitor
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 20 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Certificate: | EMI/EMC CE FCC Rohs |
|---|
Product Description
Product Description
=Product features=
12.1 Inch Open Frame Touch Lcd Monitor
800x600 / 1024x768 Resolution(Optional)
450 cd/m2
VGA Signal Input
12V 4A DC Input
Touch (Optional)
Meet FCC, CE, CCC, RoHS Certification
Operating Temp:-20~80
Product Specifications
| LCD | |
|---|---|
| Panel Type | AUO LCD Panel (Optional) |
| Resolution | 800*600 |
| Display Area(mm) | 246.0(H)*184.5(V) |
| Brightness | 400nits |
| Contrast Ratio | 600:1 |
| Colors | 16.2M/262k colors |
| View Angle | 70/70/50/60 |
| Backlight Lifetime | 50000 |
| ODS Control | Auto Menu Select(+,-)Exit On/Off |
| Touch Screen | |
|---|---|
| Type | No(Optional) |
| Resolution(pixel) | No |
| Touch Transmittance | No |
| Interface | |
|---|---|
| Signal Input | VGA+DVI(15 Pin D-sub/DVI-D Connector) AV Input/Video Input/Video Input/Audio Input(Optional) |
| Touch Connectors | USB / RS232(Optional) |
| Power | |
|---|---|
| Power Input | DC12V/4A (50~61HZ)-DC Jack (2.0mm) |
| Power Consumption | is less than or equal to 36W |
| Mechanical | |
|---|---|
| Material | Steel chassis |
| Mounting | Support VESA Wall Mount and Embedded Mount |
| Dimensions | 290.0(H)*245.0(V)*47.1(D) |
| Environment | |
|---|---|
| Operating Temp | -20~80 |
| Storage Temp | -20~80 |
| Relative Humidity | 10~90% @40Co Non-condensing without touch screen |
| Vibration | 1G peak,5~500Hz(Random) |
| Shock | 15G peak acceleration (11msec.duration) |
| Rating | Meet EMI/EMC CE FCC Rohs |
| Ordering Information | |
|---|---|
| GHK-12OP-NA | 12.1 Inch Open Frame Lcd Monitor |
| GHK-12OP-TA | 12.1 Inch Open Frame Touch Monitor |
